Fuses
Dryer
Supply voltage
Maximum fuses, mandatory type:
Class JJS-15 Bussmann type UL class T
600V
QPVS-650 (ES 310 VSD )
460 V
3 x 15 A
QPVS-850 (ES 410 VSD)
460 V
3 x 15 A
QPVS-1050 (ES 510 VSD)
460 V
3 x 15 A
Fuses
Dryer
Supply voltage
Maximum fuses, mandatory type:
Class gG ABB type OFAF000H16 000 Size
500V
QPVS-650 (ES 310 VSD)
400 V
3 x 16 A
QPVS-850 (ES 410 VSD)
400 V
3 x 16 A
QPVS-1050 (ES 510 VSD)
400 V
3 x 16 A
Electrical cable size
Dryer
Supply voltage
Supply cable section, recommended
QED-650 (ES 310 )
400 V
3 x 4 mm
2
+ 4 mm
2
QPVS-650 (ES 310 VSD)
400 V
3 x 4 mm
2
+ 4 mm
2
QED-850 (ES 410)
400 V
3 x 4 mm
2
+ 4 mm
2
QPVS-850 (ES 410 VSD)
400 V
3 x 4 mm
2
+ 4 mm
2
QED-1050 (ES 510)
400 V
3 x 4 mm
2
+ 4 mm
2
QPVS-1050 (ES 510 VSD)
400 V
3 x 4 mm
2
+ 4 mm
2
QED-650 (ES 310 )
460 V
3 X AWG 12 + AWG 12
QPVS-650 (ES 310 VSD)
460 V
3 X AWG 12 + AWG 12
QED-850 (ES 410)
460 V
3 X AWG 12 + AWG 12
QPVS-850 (ES 410 VSD)
460 V
3 X AWG 12 + AWG 12
QED-1050 (ES 510)
460 V
3 X AWG 10 + AWG 10
QPVS-1050 (ES 510 VSD)
460 V
3 X AWG 12 + AWG 12
