Qumi Q5 User Manual

47
Projection Distance vs. Projection Size
Projection Distance and Size Table
DIAGONAL
(MM/INCHES)
WIDTH
(MM/INCHES)
IMAGE HIGH
(MM/INCHES)
PROJECTION
DISTANCE
(MM/INCHES)
OFFSET-A
(MM/INCHES)
762/30 646/25.43 404/15.91 1000/39.37 10/0.40
1016/40 862/33.94 538/21.18 1340/52.76 13/0.51
1143/45 969/38.15 606/23.86 1500/59.06 15/0.59
1270/50 1077/42.40 673/26.50 1670/65.75 17/0.66
1524/60 1292/50.87 808/31.81 2000/78.74 20/0.79
1778/70 1508/59.37 942/37.09 2340/92.13 24/0.92
2032/80 1723/67.83 1077/42.40 2670/105.12 27/1.06
2286/90 1939/76.34 1212/47.72 3000/118.11 30/1.18

Qumi Q5 Specifications

General

Resolution	1280 x 800 (WXGA)
Brightness	500 ANSI Lumens
Contrast Ratio	10, 000:1
Projection Technology	DLP
Lamp Life	30, 000 Hours (LED)
Aspect Ratio	16:10
Built-in Memory	4GB
Light Source	LED
Connectivity	HDMI, USB, Audio Out
Projection Size	30" - 90"
Operating System	No
Built-in Speaker	2W
Battery Life	No
