Timing Mode Table
SIGNAL RESOLUTION
H-SYNC
(KHZ)
V-SYNC
(HZ)
COMPOSITE /
S-VIDEO
COMPONENT RGB DVI/HDMI
NTSC — 15.734 60.0 O — — —
PAL/SECAM — 15.625 50.0 O — — —
VESA
720 x 400 37.9 85.0 — — O O
800 x 600 31.5 60.0 — — O O
800 x 600 37.9 72.0 — — O O
800 x 600 37.5 75.0 — — O O
640 x 480 43.3 85.0 — — O O
800 x 600 35.2 56.0 — — O O
800 x 600 37.9 60.0 — — O O
800 x 600 48.1 72.0 — — O O
800 x 600 46.9 75.0 — — O O
800 x 600 53.7 85.0 — — O O
1024 x 768 48.4 60.0 — — O O
1024 x 768 56.5 70.0 — — O O
1024 x 768 60.0 75.0 — — O O
1024 x 768 68.7 85.0 — — O O
1280 x 800 49.7 59.8 — — O O
1280 x 800 62.8 74.9 — — O O
1280 x 800 71.6 84.8 — — O O
1280 x 1024 63.98 60.0 — — O O
1280 x 1024 79.98 75.0 —
—
O O
1280 x 960 60.0 60.0 — — O O
1280 x 960 85.9 85.0 — — O O
1400 x 1050 65.3 60.0 — — O O
1440 x 900 70.6 75.0 — — O O
1440 x 900 55.6 60.0 — — O O
Apple
®
Mac
640 x 480 35.0 66.68 — — O O
832 x 624 49.725 74.55 — — O O
1024 x 768 60.24 75.0 — — O O
1152 x 870 68.68 75.06 — — O O
SDTV
480i 15.734 60.0 — O — O
576i 15.625 50.0 — O — O
EDTV
480p 31.469 60.0 — O — O
576p 31.25 50.0 — O — O
HDTV
720p 37.5 50.0 — O — O
720p 45.0 60.0 — O — O
1080i 33.8 60.0 — O — O
1080i 28.1 50.0 — O — O
1080p 67.5 60.0 — O — O
1080p 56.3 50.0 — O — O
O: Frequency supported
—: Frequency not supported
*: Displayable level
