2.4 Rada Pulse 124, 125, 126 Sensor
2.3 Rada Pulse LR Sensor
55 mm
15 mm
78 mm dia
128 mm dia
9.5 mm to 25 mm
16 mm
Note!
The
M6
xing
studs
supplied
allow
the
LR
sensor
to
be
attached
through
a
wall
to
a
maxi
mum
thi
ckness
of
165 mm.
If
longer
M6
xing
studs
are
require
d,
these
will have to be purchased through your local supplier
.
Finished W
all
170 mm maximum
75 mm
75 mm
12
