3.2 SV2022/SV2028 Solenoid Valve
Supply Voltage: 12 V AC, 50/60 Hz.
Rating: 8 VA.
Body Material: Brass.
Connections: SV2022 3/4" BSP female connections.
SV2028 1" BSP female connections.
Min / Max Pressures: 20 to 1000 kPa (0.2 to 10 bar).
Type: Servo assisted.
3.3 SV3022 Solenoid Valve
Note! A maximum of 5 SV3022 Solenoid Valves may be used on one Rada Pulse
control system.
Supply Voltage: 12 V AC, 50/60 Hz.
Rating: 13 VA.
Body Material: Brass.
Connections: 3/4" BSP female connections.
Min / Max Pressures: 0 - 800 kPa (0 - 8 bar).
Type: Lift assisted.
Maximum cable runs for solenoid connections are as follows:
SV1015
Cable Size mm
2
Max Length in Metres
0.50 27
0.75 40
1.0 53
2.0 104
SV2022 SV2028 SV3022
Cable Size mm
2
Max Length in Metres
0.50 7.5
0.75 10.5
1.0 14
2.0 28
