OVERVIEW
The PZ-Pro may appear complicated due to the many available features
and conguration options, but it can be simplied by breaking it down into
four main sections:
INPUTS AND EQ
The PZ-Pro has two input channels, so you can have two separate sound
sources connected at the same time. Two 1/4" input jacks provide con-
nection to any instrument source, and the PZ Boost switches allow you
to optimize each input for use with piezo transducers. Channel B also
features a microphone input, so you can blend a clip on microphone with
your instrument pickups, or even connect a vocal mic.
EFX LOOP AND BOOST
Two additional features on the PZ-Pro are the EFX Loop and clean Boost,
both of which can be congured to match your playing style and your
specic setup. The EFX Loop allows you to connect your guitar eects
pedals directly to the PZ-Pro, so you can share them across both inputs,
or use them on just one source while leaving the other unaected. A wet/
dry control allows you to blend in how much of the pedal eects are added
to your sound. The Boost is a class-A signal booster with up to +15 dB of
clean gain that allows you to cut through the mix when soloing.
FOOTSWITCH CONTROL
The PZ-Pro also has three useful footswitches for real-time performance
control on a live stage. The Input footswitch toggles between the two inputs,
making instrument changeovers on stage silent and seamless. The EFX/
Loop footswitch is assignable, and can be selected to turn the EFX Loop
on and o, activate the clean Boost, or control both simultaneously. Lastly,
the Mute footswitch provides an easy way to cut output signals from the
PZ-Pro so only the Tuner out is active, allowing for quiet on stage tuning
at a moment's notice.
OUTPUTS
Two balanced DI outputs are provided on the PZ-Pro over XLR connec-
tors to feed PA systems up to 300' away without signal degradation or
noise. Pre EQ and Post EQ options are provided, and both can be used
simultaneously. This gives you the ability to send a direct feed of your
instruments to the main PA system, while taking the Post EQ shaped sound
to your monitor system for in-ears or stage wedges. In addition to the XLR
outputs, the PZ-Pro also has a 1/4" amp out to feed a stage amplier, and
a buered always-on output to feed a tuner pedal.
