17 QD134-15
5. WORKSHOP CAR MAINTENANCE
After every day the car has run the car should be inspected thoroughly in a workshop environment.
J ACK ING P OINTS
The front jacking point is in the centre of the front diffuser, just under the front chassis rail. As shown in the
picture.
The rear jacking point is under the rear section, a welded bar is situated on the chassis in the centre of the
car.
LIFTING P OINTS
To lift the car onto a high stand we recommend lifting the car with a crane, rated to at least the weight of the
car. To lift the car, mount a strap around the very top of the forward-facing stays, as shown. Be careful not to
damage the bodywork.
