RADICAL SR1 - Engine Control Parameters; Common Parts

36 QD134-15
9.3 ENGINE CONTROL PARAMETERS
Feature
Parameter
High Coolant Temperature Trip
Low Fuel Pressure Trip
2.2bar
Low Oil Pressure Trip
50psi @ 9500rpm (RPM Dependant)
Rev Limit
9725rpm
Fan On
Fan Off
Fuel Pressure Target
3.0 Bar
9.4 COMMON PARTS
Part
Description
Part Num ber
Brake Disc
Pair
BD0024
Front Master Cylinder
7/10
BM0095
Rear Master Cylinder
3/4
BM0096
Clutch Master Cylinder
5/8
BM0094
Chain
-
TC0013
Rear Sprocket
46T
TC0013
Front Sprocket
17T
TC0027
Wheel Speed Sensor
2mm airgap
LS0080
Oil Pressure Sensor
-
LS0076
Water Temp Sensor
-
LS0028
Oil Temp Sensor
-
LS0028
Air Temp Sensor
-
LS0093
Injectors
Ford Injectors (Blue)
FB0060
Spark Plugs
Without Caps
LP0011
Mirror Glass
-
AM0022
Paddle Set
-
TP0111
Fuel Pump
-
FP0030
Valve Block
-
TP0138
Driveshaft L/R
Sided
TQ0008/9
Water Pump
Electric
HP0012
Battery
-
LB0010
Caliper Seals
-
BS0002
Starter Motor
-
LM0007
Oil Filter
-
EF0003
Fuel Filter
-
FF0005
Side Skirt
Black
MA0012/G1
