8.2 CHARGING ISSUES
The SR1 should be charging between 13.5-14.5 V when running on circuit. If you see it running below this,
harging voltage in this section. Follow the
below guide on how to diagnose the problem and deciding on the solution. When checking the car is
charging, hold the RPM above 3000rpm.
Battery
Check the charging
fuse in sub loom
Trickle charge the battery, consider replacing with
a new known good battery.
Testing with a multimeter, is
it above 9V? Check for
deformation
Check/Replace
Loom
Check the
Charging Relay
Check for AC
voltage from Stator
Check/Replace
Rectifier
no
yes
Try new battery
