Radio Shack HTX-10 - Specifications

32
SPECIFICATIONS
GENERAL
Frequency Range ........................... 28.000 MHz to 29.699 MHz
Tuning Step ......................... 1 kHz/10 kHz/100 kHz (selectable)
Frequency Generation ........................... Digital PLL Synthesizer
Antenna Connector ............................ 50 ohm coaxial connector
Microphone ........................................... Electret condenser type
Operating Temperature ................... –4° to 122°F (–10° to 55°C)
Power Source ............. 12–16V DC, negative or positive ground
Speaker ................................................................ 8 ohm, 2 watt
Impedance ...................................................................... 50 ohm
Dimensions (HWD) ........................... 6
1
/
16
× 2
3
/
64
× 9
41
/
64
inches
(154 × 52 × 248 mm)
Weight (without batteries)................................................. 2.65 lb
(1.2 kg)
Accessories ............................ Microphone, Microphone Holder,
Mounting Hardware, Mounting Bracket,
DC Power Cord, Spare Fuse
RECEIVER
Sensitivity .................................................. 0.5
µ
V for 10 dB S/N
Audio Output @ 10% THD (External) ................ 2.5 W at 8 ohm
Selectivity ................................................................... 50 dB min
Intermodulation ........................................................... 60 dB min
Distortion ..................................................................... 10% max
S/N Ratio .................................................................... 40 dB min
IF Rejection ........................................................ 70 dB or better
