RD4000 Locating System User Manual
Page 10
The RD4000 features:
• LCD display
• Ease of operation
• Auto backlight
• Web enabling capability
Transmitters
Three transmitters are available:
• RD4000T3 The entry-level transmitter
• RD4000T3F This has the same features as the T3 but with FaultFind
• RD4000T10 Fully web-configurable transmitter
RD4000T3
The RD4000T3 features:
• LED display
• Three-watt power output
• Three locate frequencies
• One induction frequency.
Layout of controls and connectors
(1) Sounder (5) External power supply and optional
(2) RS232 connector. charging point
(3) Accessory connection socket (6) Battery housing-release catch
(4) LED function indicators
RD4000T3F
The RD4000T3F is identical to the RD4000 T3 with addition of FaultFind.
3
2
1
V
Ω
R
D
4
0
0
0
T
1
0
5
4
6
