RD8000 Operation Manual 5
2.2 Tx1, Tx3 and Tx10 transmitters
2.2.1 Transmitter features
Pairing icon (Tx3B and Tx10B only): Appears
when the transmitter and receiver are connected
via iLOC™.
Bluetooth
®
icon (Tx3B and Tx10B only). Indicates
status of Bluetooth
®
connection. A ashing icon
means pairing is in progress.
20.
21.
Keypad.
LCD.
Removable accessory tray.
Rechargeable battery pack.
2.2.2 Transmitter keypad
1.
2.
3.
4.
Power key : Switches the unit on and off.
Opens the transmitter menu.
Frequency key : Selects frequency. Menu
navigation key.
Up and down arrows
: Adjusts the output
signal. Scrolls through the menu options.
Measure key : Toggles measurement display
between volts, current and impedance. Note:
displayed measurements are based on the
currently selected mode or the attached
accessory, if applicable. Opens a submenu.
2.2.3 Transmitter screen icons
5.
6.
7.
8.
Battery icon: Indicates the battery level.
Alphanumeric description of selected operation
mode.
Standby icon: Appears when the transmitter is in
Standby Mode.
Output level: Displays transmitter output power.
Clamp icon: Indicates when a clamp or other plug
is connected.
DC icon: Appears when the transmitter is
powered from a DC source.
Induction indicator: Appears when the transmitter
is in Induction Mode.
A-Frame (Tx3 and Tx10 only): Indicates when the
transmitter is in Fault-Find Mode.
CD Mode indicator (Tx10 only): Indicates that the
transmitter is in Current Direction Mode.
Voltage warning indicator: Indicates that the
transmitter is outputting potentially hazardous
voltage levels.
Volume icon: Displays the volume level.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
