Radiodetection RD8000 User Manual

RD8000 Operation Manual 41
13.4 Specications for the receiver and transmitter
Sensitivity 6E-15 Tesla, 5µA at 1 meter (33Hz)
Dynamic range 140dB rms/√Hz
Selectivity 120dB/Hz
Depth accuracy Line: ± 2.5% tolerance 0.1m (4”) to 3m (10ft)
Sonde: ± 2.5% tolerance 0.1m (4”) to 7m (23ft)
Maximum depth* Line 6m (20ft), Sonde 18m (60ft)
Locate accuracy ± 2.5%
CD Fault-Finding (CDFF) 220Hz to 4kHz
Fault-Finding (FF) Diagnose cable sheath faults from short circuit to 2MΩ using the A-frame
Batteries Rx: 2 x D-cells (LR20) Tx: 8 x D-cells (LR20)
Battery life Rx: 30 hours intermittent
Tx: use dependent on signal conditions typically 15 hours
Tx rechargeable battery pack: 8-hours on high power output
Warranty 36 Months upon registration
Dynamic overload protection 30dB (automatic)
Compliance FCC, RSS 310 RoHS, Weee
Approvals
CE, Bluetooth
®
Weight Tx: = 2.84kg (6lbs) (including batteries) 4.2kg (9lbs) (including accessories)
Rx: =1.87kg (4lbs) (including batteries)
Environment IP54
13.5 Supported frequencies
Model PXL PXLB PDL PDLB
Power • • • •
Radio • • • •
Passive Avoidance • •
CATV 50/60Hz • •
CPS 100/120Hz • •
Active ELF (98/128Hz) • •
Active 570Hz • •
Active 577Hz • • • •
Active LF (512/640Hz) • • • •
Active 760Hz • •
Active 870Hz • • • •
Active 920Hz • • • •
Active 8kHz • • • •
Active 9.8kHz • •
Active 33kHz • • • •
Active 65kHz • • • •
Active 83kHz • • • •
Active 131kHz • • • •
