Radiodetection T631 TDR - Dielectric Constant (Permittivity) Known; Short Length of Same Type of Cable

Ifthe valueof the PVF or thecable type isnot known thenthe PVF can be determined as follows.
7.4.2 DIELECTRIC CONSTANT (PERMITTIVITY) KNOWN
PVF =
1
ε
Example: For polyethylene ε = 2.25
PVF ==
1
225
0667
.
.
7.4.3 SHORT LENGTH OF SAME TYPE OF CABLE
1. Measure physical length of the sample.
2. Obtain a reading for the apparent length of the cable using any PVF value.
3. Adjust the PVF value until the distance reading indicated is the same as the measured
length.
Radiodetection Ltd. 00901209-6
T631 OPERATING MANUAL 26
