Radio Appendix A
RADWIN 1000/2000/5000 User ManualVersion 2.5.30p3 A-3
5.250 – 5.350 GHz
1.9 dBm 28 dBi Dish
6.5 dBm 23.5 dBi Integral Flat
7.5 dBm 22.5 dBi External Flat
23.5dBm 6 dBi assembly
7.4 dBm 14 dBi External Flat
7.4 dBm 15.5 dBi External Flat
23.5 dBm 6 dBi assembly
5.470 – 5.725 GHz
1.6 dBm 28 dBi Dish
6.3 dBm 23.5 dBi Integral Flat
7.3 dBm 22.5 dBi External Flat
23.7 dBm 6 dBi assembly
7.2 dBm 14 dBi External Flat
7.2 dBm 16.5 dBi External Flat
23.7 dBm 6 dBi assembly
5.725 – 5.825 GHz
23.8 dBm 28 dBi Dish
26.4 dBm 22.5 dBi Integral Flat
26.4 dBm 23.5 dBi External Flat
29.4 dBm 6 dBi assembly
24.4 dBm 14 dBi External Flat
24 dBm 16.5 dBi External Flat
29.3 dBm 6 dBi assembly
4.940 – 4.990 GHz
31 dBm 21 dBi Integral Flat
31 dBm 21 dBi External Flat
31 dBm 28 dBi Dish
31 dBm 14 dBi External Flat
31 dBm 15 dBi External Flat
2.400 – 2.4835 GHz
25.5 dBm* 20 dBi External Flat
25.5 dBm* 17.5 dBi Integral Flat
23.7 dBm 20 dBi External Flat
23.7 dBm 17.5 dBi Integral Flat
3.475 – 3.650 GHz
26 dBm 21 dBi Integral Flat
26 dBm 22 dBi External Flat
26 dBm 25 dBi Dish
3.650 – 3.700 GHz 25.6 dBm 13.5 dBi assembly
Band Max Tx Power Antenna
