RADWIN 1000/2000/5000 User ManualVersion 2.5.30p3 B-1
Appendix B
Wiring Specifications
ODU-IDU Cable
The ODU-IDU cable is shielded/outdoor class CAT-5e, 4 twisted-pair 24
AWG terminated with RJ-45 connectors on both ends. A cable gland on the
ODU side provides hermetic sealing.
The following table shows the connector pinout:
User Port Connectors
LAN Port
The LAN 10/100BaseT interface terminates in an 8-pin RJ-45 connector,
wired in accordance to table B-2.
Table B-1: ODU-IDU Connector Pinout
Function Color IDU RJ-45
ODU
RJ-45
Ethernet (RxN) White/Green 1 twisted
2 pair
1
Ethernet (RxT) Green 2
Ethernet (TxT) White/Orange 3 twisted
6 pair
3
Ethernet (TxN) Orange 6
Power (+) Blue 4 twisted
5 pair
4
Power (+) White/Blue 5
Power () White/Brown 7 twisted
8 pair
7
Power () Brown 8
