Raise3D E2 - Printer Components: Back View Details Part 1; Electric Control System; Camera and LED Light Bar; Filament Handling and Power

Raise3D E2_Quick Start Guide
www.raise3d.com
- 7 -
2. Back Parts
A. Electric Control System
Includes screen components and the motion control panel. Do not open without permission.
B. Camera
Used to observe the operation of the printer.
C. LED Light Bar
Provides interior lighting of the chassis.
D. Filament Holder
Holds the filament spool, maximum weight 3 kg.
E. Input Power
AC input and switching.
F. Filament Exit
The filament leads from here to the extruder.
G. Filament Run-out Sensor
Detects when the material has run out.
F. Filament Exit
G. Filament Run-out Sensor
I. Air Filter Fan
H. Switching Power Supply
J. Ethernet Port
A. Electric Control
System
B. Camera
C. LED Light Bar
D. Filament Holders
E. Input Power
