LANESENSE WARNING MESSAGE
The LaneSense system will indicate the current lane
drift condition through the instrument cluster display.
When the LaneSense system is on, the lane lines are gray
when both of the lane boundaries have not been detected
and the LaneSense telltale
is solid white.
Left Lane Departure — Only Left Lane Detected
•
When the LaneSense system is on, the LaneSense
Telltale
is solid white when only the left lane
marking has been detected and the system is ready
to provide visual warnings in the instrument cluster
display if an unintentional lane departure occurs on
the left side.
•
When the LaneSense system senses the lane has
been approached and is in a lane departure situa-
tion, the visual warning in the instrument cluster
display will show the left lane line flashing yellow
(on/off). The LaneSense telltale
changes from
solid white to flashing yellow.
NOTE:
The LaneSense system operates with similar behavior
for a right lane departure when only the right lane
marking has been detected.
Left Lane Departure — Both Lane Lines Detected
•
When the LaneSense system is on, and both the
lane markings have been detected, the system is
ready to provide visual warnings in the instrument
cluster display and a torque warning in the steering
wheel if an unintentional lane departure occurs. The
lane lines turn from gray to white and the Lane-
Sense telltale
is solid green.
•
When the LaneSense system senses a lane drift situa-
tion, the left lane line turns solid yellow. The LaneSense
telltale
changes from solid green to solid yellow. At
this time torque is applied to the steering wheel in the
opposite direction of the lane boundary.
For example: If approaching the left side of the lane
the steering wheel will turn to the right.
System ON (Gray Lines) With White Telltale
Lane Crossed (Flashing Yellow Lane Line) With Yellow
Telltale
Lanes Sensed (White Lines) With Green Telltale
Lane Approached (Solid Yellow Lane Line) With Solid
Yellow Telltale
138 STARTING AND OPERATING
