Zoom View
When the Rear View image is being displayed, and the
vehicle speed is below 8 mph (13 km/h) while in any
gear, Zoom View is available. By pressing the “magnify-
ing glass” icon in the upper left of the display screen,
the image will zoom in to four times the standard view.
Pressing the icon a second time will return the view to
the standard Rear View.
When Zoom View is selected while the vehicle is in
REVERSE, then shifted to DRIVE, the camera delay view
will display the standard Back Up Camera view. If the
vehicle is then returned to REVERSE gear from DRIVE,
the Zoom View selection will automatically resume.
Shifting to NEUTRAL from any gear will maintain the
selected view (Zoom or Standard) as long as the vehicle
speed is below 8 mph (13 km/h).
If the vehicle is in PARK, Zoom View is available until
the gear selector is placed in DRIVE or REVERSE and
speeds are at or above 8 mph (13 km/h).
NOTE:
•
If the vehicle is in DRIVE, NEUTRAL, or REVERSE,
and speed is greater than or equal to 8 mph
(13 km/h), Zoom View is unavailable and the icon
will appear gray.
•
While in Zoom View, the guidelines will not be visible.
Deactivation
The system is deactivated in the following conditions if
it was activated automatically:
•
When the vehicle is shifted out of REVERSE with
camera delay turned on, the camera image will con-
tinue to be displayed for up to 10 seconds unless
the vehicle speed exceeds 8 mph (13 km/h), the
vehicle is shifted into PARK or the ignition is placed
in the OFF position. There is a touchscreen X button
to disable the display of the camera image.
•
When the vehicle is shifted out of REVERSE with
camera delay turned off, the Surround View Camera
mode is exited and the last known screen appears
again.
The system is deactivated in the following conditions if
it was activated manually from the Uconnect controls
menu via the Surround View Camera button, Back Up
Camera button, Cargo Camera button or Forward Fac-
ing Camera button:
•
The touchscreen X button on the display is pressed
•
Vehicle is shifted into PARK
•
Ignition is placed in the OFF position
•
Vehicle speed is over 8 mph (13 km/h) for
10 seconds
NOTE:
If the Surround View Camera, Cargo Camera, Back Up
Camera, or Forward Facing Camera is activated manu-
ally, and the vehicle is shifted into REVERSE, deactiva-
tion methods for automatic activation are assumed.
The camera delay system is turned off manually
through Uconnect Settings
page 165.
NOTE:
•
If snow, ice, mud, or any foreign substance builds up
on the camera lenses, clean the lenses, rinse with
water, and dry with a soft cloth. Do not cover the
lenses.
•
If a malfunction with the system has occurred, see
an authorized dealer.
Cargo Camera Zoom View
When the Cargo Camera image is being dis-
played, and the vehicle speed is below
8 mph (13 km/h) while in any gear selector
position, Zoom View is available. By pressing
the “magnifying glass” icon in the upper left of the dis-
play screen, the image will zoom in to four times the
standard view. Pressing the icon a second time will
return the view to the standard Cargo Camera display.
When Zoom View is selected while the vehicle is in
REVERSE, then shifted to DRIVE, the camera delay view
will display the standard Cargo Camera view. If the
vehicle is then returned to REVERSE gear from DRIVE,
the Zoom View selection will automatically resume.
Shifting to NEUTRAL from any gear will maintain the
selected view (Zoom or Standard) as long as the vehicle
is below 8 mph (13 km/h).
Zoom View is available until the gear selector is placed
in DRIVE or REVERSE and speeds are at or above
8 mph (13 km/h).
NOTE:
•
If the vehicle is in DRIVE, NEUTRAL, or REVERSE,
and speed is greater than or equal to 8 mph
(13 km/h), Zoom View is unavailable and the icon
will appear gray.
•
While in Zoom View, the dynamic centerline will not
be visible.
Forward Facing Camera With Tire Lines — If Equipped
The Forward Facing Camera displays a front view image
of the road ahead, along with tire lines to guide the
driver when driving on narrow roads. Tire lines can be
activated/deactivated through the Uconnect Settings.
STARTING AND OPERATING 143
