Hiding the status bar
You can hide the status bar display, e.g. in order to enlarge the display area
for the measurement results.
1. Press the [DISPLAY] key.
2. In the "Display Settings" dialog box, select "Status Bar State: Off".
The status bar is no longer displayed.
●
To display the status bar again, select "Status Bar State: On".
SCPI command:
DISP:SBAR:STAT OFF
The following information is displayed:
Instrument status
The instrument is configured for operation with an external reference.
Progress
The progress of the current operation is displayed in the status bar.
Date and time
The date and time settings of the instrument are displayed in the status bar.
6.2 Means of User Interaction
The instrument provides a user interface for operation that does not require an
external keyboard, using the following means of interaction:
●
Chapter 6.2.1, "Toolbar", on page 54
●
Chapter 6.2.2, "Touchscreen", on page 55
●
Chapter 6.2.3, "On-screen Keyboard", on page 56
