Instrument control
R&S
®
LCX Series
49Getting Started 1179.2254.02 ─ 03
For data input in dialogs, the instrument provides on-screen keypads for entering
numeric and alphanumeric values. Thus, you can always set the parameters
using the touchscreen, or the navigation controls at the front panel.
To correct an entry
1. To delete an entry, set the cursor to the right of the entry you want to delete.
To select the position:
a) Select (tap) it in the entry field directly.
b) Use the cursor softkeys of the on-screen keypad.
c) Use the [◀], or [▶] keys at the front panel.
2. On the on-screen keypad, select "Clear".
Deletes the entry to the left of the cursor.
3. Enter your correction.
To complete the entry
To confirm the entry:
► On the on-screen keyboard, select
(confirm).
To abort the entry
► On the on-screen keypad, select "ESC".
The dialog closes without changing the settings.
Pressing the [rotary knob] also cancels the action and returns to the previous
screen.
6.2.3.1 Entering numeric parameters
To enter values with the on-screen keypad
For numeric settings, the instrument displays the numeric keypad. The units
specified correspond to the units of the parameter.
1. Enter the numeric value.
2. Select the unit button to complete the entry.
The unit is added to the entry.
Means of manual interaction
