Command reference
R&S
®
ZNA
1133User Manual 1178.6462.02 ─ 20
Parameters:
<Voltage> Range: -6 to +12 V
Increment: 0.005 V
Default unit: V
Manual operation: See "GPIO columns (sweep sequencer table)" on page 611
CONTrol<Ch>:SEQuence<Nr>:RFFE<Bus>:COMMand:DATA <Command>
For unsegmented sweeps this command allows to define the RFFE command(s) to be
executed at the start of each sweep.
Command execution on an RFFE interface can be enabled/disabled using
CONTrol<Ch>:RFFE<Bus>:SETTings[:STATe]. Complementary GPIO switches
can be defined using CONTrol<Ch>:SEQuence<Nr>:GPIO<Port>:VOLTage.
Suffix:
<Ch>
.
Channel number
<Nr> Sequence number, defining the order in which the commands
shall be executed.
For every channel and RFFE interface, the sequence numbers
must be consecutive, starting at 1; reusing a sequence number
overwrites a previously defined command.
Delays between subsequent commands and - finally - the start
of the respective sweep can be introduced using
CONTrol<Ch>:SEQuence<Nr>:DELay
<Bus> RFFE bus interface number
Parameters:
<Command> 3 to 37 hexadecimal digits (0-F), defining the command to be
executed: digit 1 is the slave address, digits 2 and 3 specify the
command number and the remaining digits represent the data
part (up to 17 digit pairs).
Manual operation: See "RFFE columns (sweep sequencer table)" on page 611
CONTrol:VSE:ADDRess <Adress>
Sets/gets the VISA address of a remote R&S VSE instance.
Parameters:
<Adress> VISA resource string
Manual operation: See "VISA address list" on page 646
CONTrol:VSE:CONFig:LOAD <FilePathOnVna>
If a connection to a R&S VSE instance is established, you can load its configuration
from a file on the R&S ZNA (previously created using Save VSE Configuration).
SCPI command reference
