Preparing for Use
R&S
®
ZNLE
26Getting Started 1323.2873.02 ─ 07
To fix the mapping between touchscreen and display, connect an external monitor
to the R&S ZNLE and proceed as follows:
1. Select [Setup] > "Display" > "Configure Monitor" > "Display Switch" to bring up
the Windows 10 "PROJECT" notification window.
Or press [Win]+[P] on a connected keyboard.
2. Select "Extend".
3. In the Windows task bar, search for "tablet" and select "Tablet PC Settings"
4. In the "Tablet PC Settings" dialog, select "Setup…". Enter the administrator
password to proceed.
Observe the message "Touch this screen to identify it as the touchscreen" on
the internal touch screen.
5. Tap on the internal touch screen.
6. Press [ENTER].
Observe the message "Touch this screen to identify it as the touchscreen" on
the external screen.
7. If the external monitor is also a touchscreen, tap on it.
8. Press [ENTER].
Touch screen operation functions correctly now. Use the "PROJECT" flyout
again to select the appropriate display mode.
Refer to the "Versions + Options" tab of the [Setup] > "System Configura-
tion" dialog to determine the "Image" version of your instrument.
4.5 Setting Up a Network (LAN) Connection
A LAN connection is the prerequisite for all network operations. The LAN connec-
tion settings can be configured directly in the Windows operating system.
The R&S ZNLE is equipped with a network interface and can be connected to an
Ethernet LAN (local area network). Provided the network administrator has
assigned you the appropriate rights and adapted the Windows firewall configura-
tion, you can use the interface, for example:
Setting Up a Network (LAN) Connection
