Preparing for Use

R&S

ZNLE

24Getting Started 1323.2873.02 ─ 07

4.4 Connecting an External Monitor

You can connect an external monitor (or projector) to the "DVI" connector on the

rear panel of the R&S ZNLE (see also Chapter 5.2.5, "DVI", on page 45).

Screen resolution and format

The touchscreen of the R&S ZNLE is calibrated for a 16:10 format. If you

connect a monitor or projector using a different format (e.g. 4:3), the calibra-

tion is not correct and the screen does not react to your touch actions prop-

erly.

The touchscreen has a screen resolution of 1280x800 pixels. Most external

monitors have a higher screen resolution. If the screen resolution of the

monitor is set higher than the instrument's resolution, the application win-

dow uses an area of 1280x800 pixels on the monitor display. For full screen

display, adjust the monitor's screen resolution.

The R&S ZNLE supports a minimum resolution of 1280x768 pixels.

1. Connect the external monitor to the R&S ZNLE.

2. Press the [SETUP] key.

3. Press the "Display" softkey.

4. Select the "Configure Monitor" tab in the "Display" dialog box.

The standard Windows "Screen Resolution" dialog box is displayed.

Connecting an External Monitor
