5.2.4 Trigger In
Use the female Trigger In connector to input an external trigger or gate data.
Thus, you can control the measurement using an external signal. The voltage
level is 1.4 V. The typical input impedance is 10 kΩ.
5.2.5 DVI
You can connect an external monitor or other display device to the R&S ZNLE via
the DVI (Digital visual interface) connector to provide an enlarged display.
For details, see Chapter 4.4, "Connecting an External Monitor", on page 24.
5.2.6 LAN
The "LAN" interface can be used to connect the R&S ZNLE to a local network for
remote control, printouts or data transfer. The assignment of the RJ-45 connector
supports twisted-pair category 5 UTP/STP cables in a star configuration (UTP
stands for unshielded twisted pair, and STP for shielded twisted pair).
For details, see Chapter 4.5, "Setting Up a Network (LAN) Connection",
on page 26.
5.2.7 USB
The rear panel provides two additional female USB (3.0 standard) connectors to
connect devices like a keyboard, a mouse or a memory stick (see also Chap-
ter 5.2.7, "USB", on page 45).
