Operating the Instrument
R&S
®
ZNLE
68Getting Started 1323.2873.02 ─ 07
Correcting an entry
1. Using the arrow keys, move the cursor to the right of the entry you want to
delete.
2. Press the [BACKSPACE] key.
The entry to the left of the cursor is deleted.
3. Enter your correction.
Completing the entry
► Press the [ENTER] key or the rotary knob.
Aborting the entry
► Press the [ESC] key.
The dialog box is closed without changing the settings.
7.4 Touchscreen Gestures
A touchscreen allows you to interact with the software using various finger ges-
tures on the screen. The basic gestures supported by the software and most
applications are described here. Further actions using the same gestures may be
possible.
Tapping
Touch the screen quickly, usually on a specific element.
You can tap most elements on the screen; in particular, any elements you can
also click on with a mouse pointer.
Figure 7-2: Tapping
Touchscreen Gestures
