SPECIFICATIONS 4
4.1 ENGINE SPECIFICATION ______________________________________________
Model: D1105-T-E3B-RNUK-3
Type:
Vertical, water-cooled, 4-cycle diesel
engine
Number of Cylinders 3
Bore & Stroke 78mm x 78.4mm
Total Displacement 1123cm³
Combustion Chamber Spherical type (E-TVCS)
Intake System Turbo charged
Gross Intermittent Power 24.5kW @ 3000rpm
Maximum Speed: 3150 ± 50 RPM (No load)
Idle Speed: 1650 ± 50 RPM
Order of Firing 1-2-3
Direction of Rotation
Counter-clockwise (viewed from flywheel
side)
Injection Pump Bosch MD type mini pump
Injection Pressure 13.73 MPa (140kgf/cm²)
Injection Timing (Before T.D.C.) 19°
Compression Ratio 23:1
Fuel: No. 2-D Diesel fuel (ASTM D975)
Lubrication (API Classification) Above CD grade
Oil Sump Capacity: 5.1 litres
Dimensions (length x width x height) 497.8mm x 396mm x 608.7mm
Dry Weight 110kg
Starting System Cell starter (with glow plug)
Starting Motor 12V, 1.0kW
Charging Generator 12V, 360w
