13 FUSES AND RELAYS
13.1 FUSE AND RELAY IDENTIFICATION____________________________________
Fuse Number Function
1 Left Hand Side Lamps
2 Right Hand Side Lamps
3 Left Hand Head Lamps
4 Right Hand Head Lamps
5Beacon
6 Plus One Supply
7 Ignition On Circuits
8 Direction Indicators
9 Hazard Lamps
10 Cutting Unit Position Switches
11 Spare
12 Air Seat Supply
13 Inclinometer
14 Lights Master Fuse
15 Horn / Lamp Flash
16 Accessory Socket
Relay Number Function
R1 LED Flasher Unit (When Fitted)
R2 Glow Heater Relay
R3 Starter Solenoid Control Relay
R4 Master Relay
