6 CONTROLS
6.2E CUTTING UNIT SWITCH (PTO) _____________________________________
To commence cutting ensure speed limiter is in mow
position and the units have been lowered.
Push bottom of the rocker switch and move joystick
towards the lower position.
To stop cutter unit rotation push top of rocker switch.
Cutting units stop rotating automatically when raised or
the operator leaves the seat.
6.2F BACKLAP SWITCH_______________________________________________
Switches the direction of cylinder rotation to
allow backlapping.
By sliding back the orange button on the
rocker switch on the control panel and
depressing the switch backlap is engaged.
When backlapping is complete return switch
to normal operating position and the lock will
engage.
6.2G 4 WHEEL DRIVE IN REVERSE SWITCH ______________________________
Engages 4 wheel drive whilst the vehicle is
reversing. The switch must be held to
engage.
