SPECIFICATIONS 12
12.7 CUTTER DECK SPECIFICATION ________________________________________
NOTE
These cutting units are made to cut grass of maximum height 82 mm down to the available height of cut range.
12.8 CUTTING PERFORMANCE_____________________________________________
2.9m (9ft 6in) width of cut:
3.17 hectares/hr. At 12 kph.
7.20 acres / at 7.5mph
(10% allowance is included for normal overlaps and turning at the end of each cut).
3.2m (10ft 7in) width of cut:
3.5 hectares/hr. At 12 kph.
8.65 acres / at 7.5mph
(10% allowance is included for normal overlaps and turning at the end of each cut).
3.5m (11ft 5in) width of cut:
3.85 hectares/hr. At 12 kph.
9.50 acres / at 7.5mph
(10% allowance is included for normal overlaps and turning at the end of each cut).
152 cm (60 inch)
Deck (Front)
89 cm (35 inch) Deck
(Wing)
101.6 cm (40 inch)
Deck (Wing)
111.8 cm (44 inch)
Deck (Wing)
Construction
Bull nose profile, steel construction. Solid bumper rails, bolted assembly of all impact and
wearing parts.
Blade Length
533.4 mm
(21 inch)
457.2 mm
(18 inch)
533.4 mm
(21 inch)
585.5 mm
(23 inch)
Number of Blades 3 2 2 2
Blade Tip Speed
4207 m/minute
(13 802 feet/
minute)
4940 m/minute
(16 207 feet/minute)
4207 m/minute
(13 802 feet/minute)
4608 m/minute
15 118 feet/minute)
Overall Width Of Cut
299.5 cm
(118 inch)
328.4 cm
(129.3 inch)
347.9 cm
(137 inch)
Height of Cut 25 mm - 120 mm (1 inch - 4.75 inch) 6.5 mm (0.25 in) increments. Tools-less adjustment.
Height of Cut Adjust-
ment Front
Six castor wheels, with spacers. tyres 9 x 3.50 - 4.00 smooth, semi pneumatic puncture proof,
sealed precision ball bearings.
Height of Cut Adjust-
ment Rear
Front deck pin and slot. Wing deck chain and Pin
“Anti Scalp” Roll Three anti scalp rollers on the front of deck and four anti scalp rollers on the rear.
Transmission By Hydraulic motor to each cutter blade.
