en-95
FUSES, RELAYS AND CONTROLLER 11
FUSES
FUSE HOLDER 1
Fuse Rating Protected Circuits
1
2
3 7.5A EM Positive to Fuel Pump
4 10A Key Switch to Beacon And Horn
5 7.5A Key Switch to Proximity Switches and Pressure Switches
6 10A Key Switch to Accessory Sockets
FUSE HOLDER 2
Fuse Rating Protected Circuits
1 20A Key Switch to Machine Control Unit
2 10A Key Switch to Air Seat
3 5A Key Switch to Mow Switch
4 5A Key Switch to Visual Display
5 5A Key Switch to Alternator
6 5A Key Switch to Transport Lock Solenoids
FUSE HOLDER 3
Fuse Rating Protected Circuits
1 5A Battery Positive Distribution Box to DSG Tracker
2 10A Battery Positive Distribution Box to Hazard Switch
3 5A Key Switch to Indicators
4 15A Key Switch to Front Head Lights
5 7.5A Key Switch to Side, Rear, Brake And Reverse Lights
6
