FUSES, RELAYS AND CONTROLLER 11
RELAYS
FUSE HOLDER 4
Fuse Rating Protected Circuits
1 20A Battery Positive Distribution Box to Machine Control Unit Positive
Splice A
2 20A Battery Positive Distribution Box to Machine Control Unit Positive
Splice B
3 25A Battery Positive Distribution Box to Engine Master Relay
4 5A Splice to Start Circuit Signal
5 20A I/P from M Positive Splice to O/P to Engine Control Unit
6 7.5A I/P from M Positive Splice to EGR, MAF And SVC Connectors
MAXI FUSE 5
Fuse Rating Protected Circuits
1 40A Battery Positive Distribution Box to Glow Plug Relay
2 40A Battery Positive Distribution Box to Cab Connector
Relay Rating Circuits
R1 40A Ignition Relay
R2 Micro Start Relay
R3 70A Glow Plug Relay
R4 Micro Engine Master Relay
R5 40A Indicator Relay
