Rational COMBIMASTER Original Installation Manual

29
5 Setting up the device
Handle storage The included holder provides a secure place to
store the mobile oven rack handle during cook-
ing. Insert the holder into the left side wall of the
unit. Remove the side wall to mount the holder.
Then attach the handle.
NSF cover panel For hygiene reasons and in accordance with NSF
Standard 4 or DIN EN 203-3, a cover panel must
be installed over the ball cock or the cleaning
pump on Units 21 and 22.
This cover is included with the unit.

Rational COMBIMASTER Specifications

General

Manufacturer	Rational
Category	Oven
Type	Combi Oven
Cleaning	Automatic cleaning system
Power Consumption	Varies by model
Steam Injection	Yes
Dimensions	Varies by model
Weight	Varies by model
Temperature Range	30-300°C
Cooking Modes	Convection, steam, combination
Capacity	10-20 gastronorm containers
