Rational iVario Original Installation Manual

4 | Installation
en-US
80.51.916_iVario-iVarioPro_WiFi-Adapter_IM_US-nord 5 / 24
4 Installation
4.1 Mounting the WiFi adapter
DANGER
High voltages during connection to the
power grid
Danger to life when working with high
voltage.
n
Disconnect the connection from the
power supply.
n
Ensure that the unit is de-energized.
Mounting the WiFi adapter
iVario, iVario Pro
a Make sure that the unit which the WiFi
adapter is to be connected to is
switched off and disconnected from
mains power.
a The electrical compartment is open.
1. Screw both antennas on the WiFi
adapter.
2. Punch out one of the perforations for
the cable gland with a suitable tool
[
Figure 11].
3. Mount the cable gland on the punched
out position. Feed the cable with both
connectors through the cable gland.
4. Connect the power supply to the I/O
card [
Figure 12].
5. Set up the WiFi adapter (see 4.2 Set-
ting up the WiFi adapter).
6. Connect the Ethernet cable to the in-
side of the control panel on the CPU
circuit board [
Figure 13] or the
outer Ethernet port [
Figure 14].
7. Feed the cable out of the unit. Roll up
the cable outside the unit.
8. Mount the WiFi adapter in a suitable
position [
Figure 08].
> The WiFi adapter can be fixed or
screwed in selected positions. We
recommend mounting it in the cen-
ter on the rear of the stand or
mounting on the wall.
4.2 Setting up the WiFi adapter
DANGER
High voltages during connection to the
power grid
Danger to life when working with high
voltage.
n
Work on the switched-on unit with
the electrical compartment open
may only be carried out by trained
personnel.
n
Work on the switched-on device
may only be carried out with suitable
protective clothing.
4.2.1 Use as a WiFi client adapter
a The electrical compartment is open.
a The device is switched on.
1. Connect the Ethernet cable of the WiFi
adapter to a computer.
2. Ensure that the WiFi on the computer
is deactivated during the configura-
tion.
Logging in
1. In a web browser, open the address
https://192.168.11.1 or a different pre-
viously set IP address. Accept the nec-
essary certificates.

Rational iVario Specifications

General

Material	Stainless steel
Model	iVario
Power Supply	400V, 3-phase
Cooking Levels	10 or 20
Dimensions	Varies by model. See specific model specifications for details.
Weight	Varies by model. See specific model specifications for details.
Programs	Multiple programmable cooking programs
Control	Touchscreen
Heating System	Electric
iCookingSuite	Yes
iZoneControl	Yes
Integrated drain	Yes
Display	Color touchscreen
Connectivity	Ethernet
