4 | Installation
en-US
6 / 24 80.51.916_iVario-iVarioPro_WiFi-Adapter_IM_US-nord
2. Enter the user name and the password
on the screen. The user name is set as
root
and the password as
Rational
as
standard [
Figure 15].
> Press the
Login
button.
NOTE
Change the initial password to prevent
misuse
During the first configuration, set a new
password in the System /
Administration menu.
Connecting the adapter with a WiFi
Access Point
NOTE
The network type during connection
must be taken into account
The WiFi adapter can not be used in a
captive portal (e.g. a guest WiFi) or a
WPA2-Enterprise-based WiFi network.
1. In the Network/WiFi menu, press the
Browse
button [ Figure 16].
2. Select the desired network. Confirm
the network with the
Join Network
button.
3. In the
WPA key
input line, enter the
WiFi password [
Figure 17]. Con-
firm the entry with the
Submit
button.
4. Confirm the entry with the
Save
but-
ton.
5. Confirm with the
Save & Apply
button.
> The signal strength of the selected
WiFi is shown in the overview
[
Figure 18]. If the password has
been entered incorrectly, 0% ap-
pears in the overview. The process
must be repeated from point/line
1. The settings can be changed by
pressing the
Edit
button.
6. Carry out a test. Open any web ad-
dress in your browser.
7. Connect the Ethernet cable to the Eth-
ernet interface on the device.
8. Close the electrical compartment.
9. Activate the network settings of the
device DHCP.
10. Restart the device.
>> The device is connected to WiFi.
1. Activate the ConnectedCooking option
in the settings for the device.
>> You will receive an activation code for
registering the unit in Connected-
Cooking. Further information on Con-
nectedCooking is available in the Con-
nectedCooking manual.
4.2.2 Use as a repeater for expanding
the existing WiFi coverage
NOTE
Repeater mode requires a permanent
power supply
To enable the repeater mode to be
used, the device must be switched on
with the connected WiFi adapter.
NOTE
Number of connected units in Repeater
mode
Only a limited number of units can be
connected with the WIFI adapter in
Repeater mode:
n
With iVario or iVario Pro: max. 10
units
