6 | Electrical connection
80.06.070_iCombi Pro-iCombi Classic_IM_V01_en-GB 57 / 92
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
20-1/1 E (3 AC 208 V) 60 103.3 37.2 125 B
20-2/1 E (3 AC 208 V) 60 188.5 67.9 200 B
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-2/3 (3 AC 220 V) 50/60 14.4 5.3 20 B
6-1/1 E (3 AC 220 V) 50/60 26 9.9 32 B
6-2/1 E (3 AC 220 V) 50/60 54.1 20.6 63 B
10-1/1 E (3 AC 220 V) 50/60 45.4 17.3 50 B
10-2/1 E (3 AC 220 V) 50/60 90 34.3 100 B
20-1/1 E (3 AC 220 V) 50/60 89.5 34.1 100 B
20-2/1 E (3 AC 220 V) 50/60 163.8 62.4 200 B
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-2/3 (3 AC 230 V) 50/60 14.9 5.7 16 B
6-1/1 E (3 AC 230 V) 50/60 27.1 10.8 32 B
6-2/1 E (3 AC 230 V) 50/60 56.2 22.4 63 B
10-1/1 E (3 AC 230 V) 50/60 47.4 18.9 50 B
10-2/1 E (3 AC 230 V) 50/60 93.9 37.4 100 B
20-1/1 E (3 AC 230 V) 50/60 93.4 37.2 100 B
20-2/1 E (3 AC 230 V) 50/60 170.4 67.9 200 B
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-2/3 (3 AC 240 V) 50/60 18 6.2 20 B
6-1/1 E (3 AC 240 V) 50/60 35 10.8 40 B
6-2/1 E (3 AC 240 V) 50/60 71 22.4 80 B
10-1/1 E (3 AC 240 V) 50/60 61 18.9 70/75 B
10-2/1 E (3 AC 240 V) 50/60 118 37.4 150 B
20-1/1 E (3 AC 240 V) 50/60 119 37.2 150 B
20-2/1 E (3 AC 240 V) 50/60 219 67.9 250 B
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-1/1 E (3 AC 400 V) 50/60 15.6 10.8 16 B
6-2/1 E (3 AC 400 V) 50/60 32.3 22.4 35 B
10-1/1 E (3 AC 400 V) 50/60 27.3 18.9 32 B
10-2/1 E (3 AC 400 V) 50/60 54 37.4 63 B
20-1/1 E (3 AC 400 V) 50/60 53.7 37.2 63 B
