4 | Transport
24 / 92 80.06.070_iCombi Pro-iCombi Classic_IM_V01_en-GB
4.4 Transporting with carrying straps
Only transport the unit size 6-1/1 up to 10-2/1 GN with carrying straps.
CAUTION
Risk of crushing and injury if unit is incorrectly lifted with carrying straps
Hands, fingers or feet could be crushed.
n
Observe the maximum load indicated on the carrying straps. Only lift the
unit according to the maximum load of the carrying straps.
n
Only lift the unit by hand using all four carrying straps. Do not use any
mechanical aids to lift the unit.
NOTICE
Risk of damage to the unit
Only transport the unit size 6-1/1 up to 10-2/1 GN with carrying straps
provided by the manufacturer. The carrying straps are not included in the
delivery and must be ordered separately (article number 91.01.135).
a All side panels of the unit must be closed.
1. Slide the gasket upwards from the slot in the base frame.
2. Put the carrying strap into the side vent with the top side upwards on the
unit sides, so that they lock in. There are two side slots for carrying straps
on each side of the unit underneath the floor gasket. Note the markings on
the top side of the carrying strap. Insert the carrying straps up to the mark
on the metal buckle.
3. Pull on the carrying straps and make sure that the carrying straps are se-
curely locked into place.
