6 | Electrical connection
60 / 92 80.06.070_iCombi Pro-iCombi Classic_IM_V01_en-GB
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-1/1 G (1 NAC 120 V) 60 5.1 0.61 15 F
10-1/1 G (1 NAC 120 V) 60 7.6 0.91 15 B
20-1/1 G (1 NAC 120 V) 60 10.8 1.3 15 F
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-1/1 G (1 NAC 127 V) 50/60 4.7 0.6 15 F
10-1/1 G (1 NAC 127 V) 50/60 7.2 0.91 15 B
20-1/1 G (1 NAC 127 V) 50/60 10.2 1.3 15 F
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-1/1 G (1 NAC 230 V) 50/60 2.6 0.6 15 F
6-2/1 G (1 NAC 230 V) 50/60 3.9 0.9 15 B
10-1/1 G (1 NAC 230 V) 50/60 4 0.91 15 B
10-2/1 G (1 NAC 230 V) 50/60 6.3 1.46 15 B
20-1/1 G (1 NAC 230 V) 50/60 5.7 1.3 15 F
20-2/1 G (1 NAC 230 V) 50/60 9.3 2.15 15 B
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-1/1 G (1 NAC 240 V) 50/60 2.5 0.6 15 F
6-2/1 G (1 NAC 240 V) 50/60 3.8 0.9 15 B
10-1/1 G (1 NAC 240 V) 50/60 3.8 0.91 15 B
10-2/1 G (1 NAC 240 V) 50/60 6.1 1.46 15 B
20-1/1 G (1 NAC 240 V) 50/60 5.4 1.3 15 F
20-2/1 G (1 NAC 240 V) 50/60 9 2.15 15 B
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-1/1 G (2 AC 200 V) 50/60 1.9 0.38 15 B
6-2/1 G (2 AC 200 V) 50/60 3.3 0.65 15 B
10-1/1 G (2 AC 200 V) 50/60 3.8 0.75 15 B
10-2/1 G (2 AC 200 V) 50/60 6.3 1.25 15 B
20-1/1 G (2 AC 200 V) 50/60 6.0 1.2 15 B
20-2/1 G (2 AC 200 V) 50/60 9.5 1.9 15 B
Hz Current
consump-
tion (A)
Power (kW) Fuse (A) RCD type
6-1/1 G (2 AC 208 V) 60 2.9 0.6 15 B
