4 | How to work with the unit
18 / 100 Operating instructions
Model Min. fill level/pan [l] Max. fill level/pan [l]
L 10 80
XL 15 120
4.6 Maximum load sizes
Model Max. load size [kg] Max. load size pressure cooking
(option) [kg]
L 100 80
XL 150 120
Example of use
The following table explains how high the maximum load size per pan is and how much oil you need using the
chips application example.
Model Max. load size [kg] max. quantity of oil [l]
L 8 (4/basket) 30
XL 12 (4/basket) 45
4.7 Opening and closing the pan lid
CAUTION
The pan lid can be opened and closed only with jerky movements
If the pan lid mechanism is defective, there is a risk of injury.
1. Open the pan lid fully and leave open.
2. Contact your RATIONAL Service Partner.
Open pan lid
1. Press and hold the button:
> CAUTION!Scalding hazard! If the unit is in operation, hot steam may surge out of the pan. The pan lid will
open automatically as long as you press and hold the button. If you release the button, the pan lid will stop
opening.
> The button will be displayed: If you press this button, the pan lid will open automatically.
> The button starts to flash: . If you press this button, the pan lid opening will stop.
Closing pan lid
a The pan is lowered [}20].
1. Press and hold the button:
> The pan lid is closed automatically.
4.8 Filling the pan using the automatic water filling function
CAUTION
Germ formation in the automatic water filling mechanism
If you do not use the automatic water filling function daily, germs may form in the water line.
1. Clean the automatic water filling mechanism with detergent and a sponge every morning and night.
2. Rinse the automatic water filling mechanism with 3 litres of water every morning and night.
You can fill the pan with water automatically and exactly to the litre using the automatic water refill.
