INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB
Page 36 of 60
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
15.0 TECHNICAL DATA
15.1 Technical data
G8945.26
G8945IT.26
G8945V.26
G8945ITV.26
G8945V.26S
G8945ITV.26S
G8945D.26
G8945ITD.26
G8945D.26S
G8945ITD.26S
Mandrel rotation motor
0.75 kW
230/400V 50-60Hz
3ph
0.8-1.1 kW
230/400V 50Hz
3ph (*)
1.5 kW
220/240V 50-60Hz
1ph
Mandrel rotating speed
(revolutions/min)
6.5 6.5/13 0÷15
Mandrel max torque (Nm) 1200
Recommended air pressure (bar) 8-10
Maximum wheel diameter (mm) 1143 (45”)
Wheel max. width (mm) 381 (15”)
Side vane bead breaking
maximum opening (mm)
432 (17”)
Rim locking diameter 10”- 26”
Bead breaking force (roll) 1200 kg (2645 Ibs)
Bead breaking force (vane) 3600 kg (7900 Ibs)
Gear noise (dB) <80
Wheel maximum weight (Kg) 80
Weight (Kg)
316
326 (version with tubeless inflation)
370
380 (version with
tubeless inflation)
(*) 0,75 kW 110V 60Hz 1ph (on demand)
