Ravaglioli G8945D.26 - Dimensions

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB
Page 37 of 60
15.2 Dimensions
* Valid for versions with tubeless inflation
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
Fig. 57 - G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945D.26 - G8945ITD.26
