3.6 Rotating Plates
3.6.1 Rotating Plates STDA124
Rotating plates STDA124 have a disc diameter of 360 mm.
Figure 5
3.7 Pedal depressor
Is a tool used to lock brake pedal during measurement preliminary operations. It has to be
used as shown in the instructions displayed during programme.
3.8 Steering lock
is a tool used to keep vehicle steering in a fixed position.
It is used before the adjustment procedure, as shown by
the instructions displayed during programme.
UPPER PLATE WITH ANTI-
SLIP DISC
PLATE RETAINER
LEVELING SEAT
PLATE CRESCENT
