5 TRANSPORT AND INSTALLATION
5.1 Transport and unpacking
The machine is supplied packed in a box fastened to a pallet to facilitate transport. To
transport the machine to the point where it is to be installed, use a lifting and transport
mechanism such as a fork-lift truck or lift with forks.
The machine must be stored in its packaging, in a dry and ventilated environment (with a
temperature between -25° +55°C).
Never overturn or position the packaging horizontally. The pallet must always rest on a flat
and solid surface. Do not stack other packages on top of the packaging. Always position so
the instructions can be easily read.
DURING UNPACKING, ALWAYS WEAR GLOVES TO PREVENT ANY INJURY CAUSED BY
CONTACT WITH PACKAGING MATERIAL (NAILS, ETC.).
Make sure you have received all standard parts as previously listed.
The packaging material (plastic bags, polystyrene, nails, screws, wood, etc.) must be collected
up and disposed of through authorised channels, except for the pallet, which could be used
again for subsequent machine handling.
5.2 Installation
Install the machine in a dry, covered and well-lit place, possibly closed or protected against
the elements.
Before positioning the machine, make sure the place chosen complies with applicable safety
regulations and check the minimum distances from walls or other obstacles.
5.2.1 Power connections
Before connecting up the machine, carefully check:
power line specifications correspond to machine requirements as shown on the machine
plate;
there is an earth lead and this is of suitable size (section greater or same as max section
of the power cables).
that all the component parts of the power line are in good condition;
Connect the machine up to the mains by means of the 3-pole plug provided (230 V single-
phase) through the wall socket.
If the plug provided is not suitable for the wall socket, fit a plug that complies with local and
applicable regulations. This operation must be performed by expert and professional
personnel.
5.2.2 Cabinet mounting
The mounting of the cabinet model RAVTD3000ATS, NRC and HP, is simply to fix the
monitor and the positioning of the PC and printer in their housing (see chap.3.1).
The mounting of the cabinet model RAVTD3000 is shown instead in special instruction,
which is provided with the equipment.
