Instruction manual
RAVTD3000 - RAVTD3000HP
RAVTD3000NRC - RAVTD3000ATS
Code M0215 - rev.1.1
(11/2012)RAVAGLIOLI S.p.A.
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
Page 31/52
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
10.7 Vehicle alignment / direct measurement operations
To proceed to vehicle alignment and direct angle detection, you should have first carried out
measurement preliminary operations, as explained in par. 10.6 on page30 .
Figure 31
DETECTOR KEYPAD
PC KEYPAD DESCRIPTION
It goes back to
measurement
preliminary operations.
(par.10.6 on page 30)
When the alignment has been achieved, the “STOP” symbol is displayed, signalling that the
programme is taking the vehicle measurements. The programme proceeds automatically only
after the wheels have been aligned.
Processing
status
Front wheel
alignment level
display
