Ravaglioli RAVTD3000 User Manual

Instruction manual
RAVTD3000 - RAVTD3000HP
RAVTD3000NRC - RAVTD3000ATS
Code M0215 - rev.1.1
(11/2012)RAVAGLIOLI S.p.A.
Page 20/52
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
9.1 DATABASE Groups Configuration
Select "GROUPS CONFIGURATION" from programme configuration page, as explained in par.
9 on page 19.
You can edit system parameters, database profile, and specify which parts are fitted on the
machine, and parts type as well.
Figure 14
DETECTOR
KEYPAD
PC KEYPAD DESCRIPTION
It goes back to the start
configuration page.
(par. 10.1 on page 22)
It moves selection up.
It moves selection down.
It confirms selection.
Select “DATABASE” option, and confirm. The following screen will be displayed:
Figure 15
