Ravaglioli RAVTD3000 User Manual

Instruction manual
RAVTD3000 - RAVTD3000HP
RAVTD3000NRC - RAVTD3000ATS
Code M0215 - rev.1.1
(11/2012)RAVAGLIOLI S.p.A.
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
Page 19/52
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
9 PROGRAMME CONFIGURATION
To proceed to programme configuration, select F2
from the introduction page, as
explained in par. 10.1 on page 22.
You will enter a configuration menu allowing editing the different programme characteristics
according to your needs.
Figure 13
Language selection: You can select your dialogue language among the many available ones.
Configuration: programme will display the screen of Figure 14
You can edit system parameters, database profile, specify which parts are fitted on the
machine, parts type, make a Bluetooth search to couple measuring heads with cabin.
Print Menu: Print can be customised by entering workshop data, selecting the type of
desired printout, and selecting the pre-set printer (if more than one printer is connected).
Backup / Restore: In order not to run the risk to lose any vehicle and customer database
data, it is recommended to create a backup copy (data saving). We recommend using a "flash
disc" USB key for this process.
Lost or deleted data can be restored if the backup operation has been carried out, thanks to
the restore procedure.
Additional functions: programme displays screen Figure 57, from which you can access
TEST or sensor Calibration applications (reserved to skilled and authorised personnel), and
the "DATABASE MANAGEMENT", see chap. 12
DETECTOR
KEYPAD
PC KEYPAD DESCRIPTION
It goes back to the
introduction page.
(par. 10.1 on page 22)
It moves selection up.
It moves selection down.
It confirms selection.
