CHAPTER 4
20 AIM Command FLEX, Patriot MY 2017 Installation Manual
FIGURE 2. Bulkhead Connector
5. Connect the 12-pin Deutsch receptacle to the mating plug located on the center rack, below and to the left of
the Product Controller II ECU.
FIGURE 3. 12-Pin Deutsch
6. Route the connectors located “Left Boom” and “Right Boom” to the Primary AIM Command Flex nozzle cables
installed in “Primary Boom Cable Routing and Connections” on page 15.
Bulkhead Connector
12-Pin Deutsch
