PAGE 14/35 | Installation manual | 016-8000-028EN | Rev. A1
Raven Industries Inc.
STEERING SYSTEM INSTALLATION | CRX + RS1 | RAVEN EUROPE GENERIC
HYDRAULICS
1.2.1 HYDRAULIC VALVE
Figure 3 shows a manifold mounted onto a manifold
bracket with four M8 bolts. The manifold bracket is
preferably mounted at the right hand side of the
tractor (Figure 4). This is usually the side of the tractor
with the most space.
Please note!:
Make sure the connectors of the valves and the
pressure sensor can still be connected after
mounting the manifold.
FIGURE 3 MANIFOLD BRACKET WITH A
MANIFOLD AND STEERING CONTROLLER
MOUNTED
FIGURE 4 MOUNTED MANIFOLD AND HYDRAULIC
DRIVE UNIT
