MOUNTING THE CR12
The following guidelines have been established for
mounting the Field Computer:
Always contact the customer about the
terminal position in the cabin.
Always use a RAM-C or RAM-B ball
attachment. (Figure 42 & Figure 43)
Mount the terminal free of vibrations with a
solid bracket. A variety of mounting brackets
are available for this purpose.
Secure all cables in the cabin.
Mount in such a way that the display is
directed straight towards the driver.
FIGURE 42 CR12 ON A PILLAR
FIGURE 43 RAM B BALL ATTACHMENT
ON PILLAR
