4
Status Symbols
The following symbols can appear on the Home screen, and refer to the
status of the GPS, File space, or Log files.
Icon Name Description
Green Check Mark: This part of the system is
normal/enabled and all operating conditions are
met.
Yellow Caution: This part of the system is
receiving a warning. Operation can proceed
with caution. Touch this icon to view the
system warning.
Red ‘X’: The system is experiencing a problem
in this area or the user has elected to not use this
function. This problem may need to be corrected
before proceeding with operation. Touch this
icon to view the system problem.
